rewrite: use bmxtranswrap

As wrapping with ffmpeg alone didn't create valid v1.3 op1a mxf in ard zdf profile this has to be done with bmxtranswrap. This can swap audio track or silence them. But it can't insert external audio. So if external audio is provided do the swapping, muting and inserting with ffmpeg and rewrap mxf with bmxtranswrap. Else do the swapping and mu- ting with bmxtranswrap alone. Signed-off-by: Conrad Zelck <git@simpel.cc>

rewrite: use bmxtranswrap
71c759a0 · Simpel · 10dc11a4 · 71c759a0 · 71c759a0 · 10dc11a4
Commit 71c759a0 authored 1 year ago by Simpel
--- a/MXF-Track-Swap.au3
+++ b/MXF-Track-Swap.au3
@@ -3,7 +3,7 @@
 #AutoIt3Wrapper_UseX64=n
 #AutoIt3Wrapper_Res_Comment=Swaps audio tracks in mxf files.
 #AutoIt3Wrapper_Res_Description=Swaps audio tracks in mxf files.
-#AutoIt3Wrapper_Res_Fileversion=1.0.0.7
+#AutoIt3Wrapper_Res_Fileversion=1.0.0.8
 #AutoIt3Wrapper_Res_Fileversion_AutoIncrement=p
 #AutoIt3Wrapper_Res_LegalCopyright=Conrad Zelck
 #AutoIt3Wrapper_Res_SaveSource=y
@@ -307,237 +307,310 @@ WEnd

 #Region - track setting
 ; set audio tracks
-Global $g_aRouting[9]
+Global $g_aRoutingFFmpeg[9]
+Global $g_aRoutingBMX[9]
 Global $g_bMuteRouted = False
 Global $g_bExternalWavRouted = False
 ; track 1
 Select
 	Case GUICtrlRead($g_hRm1) = $GUI_CHECKED
-		$g_aRouting[1] = "1:0"
+		$g_aRoutingFFmpeg[1] = "1:0"
+		$g_aRoutingBMX[1] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR11) = $GUI_CHECKED
-		$g_aRouting[1] = "0:1"
+		$g_aRoutingFFmpeg[1] = "0:1"
+		$g_aRoutingBMX[1] = "0"
 	Case GUICtrlRead($g_hR21) = $GUI_CHECKED
-		$g_aRouting[1] = "0:2"
+		$g_aRoutingFFmpeg[1] = "0:2"
+		$g_aRoutingBMX[1] = "1"
 	Case GUICtrlRead($g_hR31) = $GUI_CHECKED
-		$g_aRouting[1] = "0:3"
+		$g_aRoutingFFmpeg[1] = "0:3"
+		$g_aRoutingBMX[1] = "2"
 	Case GUICtrlRead($g_hR41) = $GUI_CHECKED
-		$g_aRouting[1] = "0:4"
+		$g_aRoutingFFmpeg[1] = "0:4"
+		$g_aRoutingBMX[1] = "3"
 	Case GUICtrlRead($g_hR51) = $GUI_CHECKED
-		$g_aRouting[1] = "0:5"
+		$g_aRoutingFFmpeg[1] = "0:5"
+		$g_aRoutingBMX[1] = "4"
 	Case GUICtrlRead($g_hR61) = $GUI_CHECKED
-		$g_aRouting[1] = "0:6"
+		$g_aRoutingFFmpeg[1] = "0:6"
+		$g_aRoutingBMX[1] = "5"
 	Case GUICtrlRead($g_hR71) = $GUI_CHECKED
-		$g_aRouting[1] = "0:7"
+		$g_aRoutingFFmpeg[1] = "0:7"
+		$g_aRoutingBMX[1] = "6"
 	Case GUICtrlRead($g_hR81) = $GUI_CHECKED
-		$g_aRouting[1] = "0:8"
+		$g_aRoutingFFmpeg[1] = "0:8"
+		$g_aRoutingBMX[1] = "7"
 	Case GUICtrlRead($g_hRL1) = $GUI_CHECKED
-		$g_aRouting[1] = '"[L]"'
+		$g_aRoutingFFmpeg[1] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR1) = $GUI_CHECKED
-		$g_aRouting[1] = '"[R]"'
+		$g_aRoutingFFmpeg[1] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 2
 Select
 	Case GUICtrlRead($g_hRm2) = $GUI_CHECKED
-		$g_aRouting[2] = "1:0"
+		$g_aRoutingFFmpeg[2] = "1:0"
+		$g_aRoutingBMX[2] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR12) = $GUI_CHECKED
-		$g_aRouting[2] = "0:1"
+		$g_aRoutingFFmpeg[2] = "0:1"
+		$g_aRoutingBMX[2] = "0"
 	Case GUICtrlRead($g_hR22) = $GUI_CHECKED
-		$g_aRouting[2] = "0:2"
+		$g_aRoutingFFmpeg[2] = "0:2"
+		$g_aRoutingBMX[2] = "1"
 	Case GUICtrlRead($g_hR32) = $GUI_CHECKED
-		$g_aRouting[2] = "0:3"
+		$g_aRoutingFFmpeg[2] = "0:3"
+		$g_aRoutingBMX[2] = "2"
 	Case GUICtrlRead($g_hR42) = $GUI_CHECKED
-		$g_aRouting[2] = "0:4"
+		$g_aRoutingFFmpeg[2] = "0:4"
+		$g_aRoutingBMX[2] = "3"
 	Case GUICtrlRead($g_hR52) = $GUI_CHECKED
-		$g_aRouting[2] = "0:5"
+		$g_aRoutingFFmpeg[2] = "0:5"
+		$g_aRoutingBMX[2] = "4"
 	Case GUICtrlRead($g_hR62) = $GUI_CHECKED
-		$g_aRouting[2] = "0:6"
+		$g_aRoutingFFmpeg[2] = "0:6"
+		$g_aRoutingBMX[2] = "5"
 	Case GUICtrlRead($g_hR72) = $GUI_CHECKED
-		$g_aRouting[2] = "0:7"
+		$g_aRoutingFFmpeg[2] = "0:7"
+		$g_aRoutingBMX[2] = "6"
 	Case GUICtrlRead($g_hR82) = $GUI_CHECKED
-		$g_aRouting[2] = "0:8"
+		$g_aRoutingFFmpeg[2] = "0:8"
+		$g_aRoutingBMX[2] = "7"
 	Case GUICtrlRead($g_hRL2) = $GUI_CHECKED
-		$g_aRouting[2] = '"[L]"'
+		$g_aRoutingFFmpeg[2] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR2) = $GUI_CHECKED
-		$g_aRouting[2] = '"[R]"'
+		$g_aRoutingFFmpeg[2] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 3
 Select
 	Case GUICtrlRead($g_hRm3) = $GUI_CHECKED
-		$g_aRouting[3] = "1:0"
+		$g_aRoutingFFmpeg[3] = "1:0"
+		$g_aRoutingBMX[3] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR13) = $GUI_CHECKED
-		$g_aRouting[3] = "0:1"
+		$g_aRoutingFFmpeg[3] = "0:1"
+		$g_aRoutingBMX[3] = "0"
 	Case GUICtrlRead($g_hR23) = $GUI_CHECKED
-		$g_aRouting[3] = "0:2"
+		$g_aRoutingFFmpeg[3] = "0:2"
+		$g_aRoutingBMX[3] = "1"
 	Case GUICtrlRead($g_hR33) = $GUI_CHECKED
-		$g_aRouting[3] = "0:3"
+		$g_aRoutingFFmpeg[3] = "0:3"
+		$g_aRoutingBMX[3] = "2"
 	Case GUICtrlRead($g_hR43) = $GUI_CHECKED
-		$g_aRouting[3] = "0:4"
+		$g_aRoutingFFmpeg[3] = "0:4"
+		$g_aRoutingBMX[3] = "3"
 	Case GUICtrlRead($g_hR53) = $GUI_CHECKED
-		$g_aRouting[3] = "0:5"
+		$g_aRoutingFFmpeg[3] = "0:5"
+		$g_aRoutingBMX[3] = "4"
 	Case GUICtrlRead($g_hR63) = $GUI_CHECKED
-		$g_aRouting[3] = "0:6"
+		$g_aRoutingFFmpeg[3] = "0:6"
+		$g_aRoutingBMX[3] = "5"
 	Case GUICtrlRead($g_hR73) = $GUI_CHECKED
-		$g_aRouting[3] = "0:7"
+		$g_aRoutingFFmpeg[3] = "0:7"
+		$g_aRoutingBMX[3] = "6"
 	Case GUICtrlRead($g_hR83) = $GUI_CHECKED
-		$g_aRouting[3] = "0:8"
+		$g_aRoutingFFmpeg[3] = "0:8"
+		$g_aRoutingBMX[3] = "7"
 	Case GUICtrlRead($g_hRL3) = $GUI_CHECKED
-		$g_aRouting[3] = '"[L]"'
+		$g_aRoutingFFmpeg[3] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR3) = $GUI_CHECKED
-		$g_aRouting[3] = '"[R]"'
+		$g_aRoutingFFmpeg[3] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 4
 Select
 	Case GUICtrlRead($g_hRm4) = $GUI_CHECKED
-		$g_aRouting[4] = "1:0"
+		$g_aRoutingFFmpeg[4] = "1:0"
+		$g_aRoutingBMX[4] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR14) = $GUI_CHECKED
-		$g_aRouting[4] = "0:1"
+		$g_aRoutingFFmpeg[4] = "0:1"
+		$g_aRoutingBMX[4] = "0"
 	Case GUICtrlRead($g_hR24) = $GUI_CHECKED
-		$g_aRouting[4] = "0:2"
+		$g_aRoutingFFmpeg[4] = "0:2"
+		$g_aRoutingBMX[4] = "1"
 	Case GUICtrlRead($g_hR34) = $GUI_CHECKED
-		$g_aRouting[4] = "0:3"
+		$g_aRoutingFFmpeg[4] = "0:3"
+		$g_aRoutingBMX[4] = "2"
 	Case GUICtrlRead($g_hR44) = $GUI_CHECKED
-		$g_aRouting[4] = "0:4"
+		$g_aRoutingFFmpeg[4] = "0:4"
+		$g_aRoutingBMX[4] = "3"
 	Case GUICtrlRead($g_hR54) = $GUI_CHECKED
-		$g_aRouting[4] = "0:5"
+		$g_aRoutingFFmpeg[4] = "0:5"
+		$g_aRoutingBMX[4] = "4"
 	Case GUICtrlRead($g_hR64) = $GUI_CHECKED
-		$g_aRouting[4] = "0:6"
+		$g_aRoutingFFmpeg[4] = "0:6"
+		$g_aRoutingBMX[4] = "5"
 	Case GUICtrlRead($g_hR74) = $GUI_CHECKED
-		$g_aRouting[4] = "0:7"
+		$g_aRoutingFFmpeg[4] = "0:7"
+		$g_aRoutingBMX[4] = "6"
 	Case GUICtrlRead($g_hR84) = $GUI_CHECKED
-		$g_aRouting[4] = "0:8"
+		$g_aRoutingFFmpeg[4] = "0:8"
+		$g_aRoutingBMX[4] = "7"
 	Case GUICtrlRead($g_hRL4) = $GUI_CHECKED
-		$g_aRouting[4] = '"[L]"'
+		$g_aRoutingFFmpeg[4] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR4) = $GUI_CHECKED
-		$g_aRouting[4] = '"[R]"'
+		$g_aRoutingFFmpeg[4] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 5
 Select
 	Case GUICtrlRead($g_hRm5) = $GUI_CHECKED
-		$g_aRouting[5] = "1:0"
+		$g_aRoutingFFmpeg[5] = "1:0"
+		$g_aRoutingBMX[5] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR15) = $GUI_CHECKED
-		$g_aRouting[5] = "0:1"
+		$g_aRoutingFFmpeg[5] = "0:1"
+		$g_aRoutingBMX[5] = "0"
 	Case GUICtrlRead($g_hR25) = $GUI_CHECKED
-		$g_aRouting[5] = "0:2"
+		$g_aRoutingFFmpeg[5] = "0:2"
+		$g_aRoutingBMX[5] = "1"
 	Case GUICtrlRead($g_hR35) = $GUI_CHECKED
-		$g_aRouting[5] = "0:3"
+		$g_aRoutingFFmpeg[5] = "0:3"
+		$g_aRoutingBMX[5] = "2"
 	Case GUICtrlRead($g_hR45) = $GUI_CHECKED
-		$g_aRouting[5] = "0:4"
+		$g_aRoutingFFmpeg[5] = "0:4"
+		$g_aRoutingBMX[5] = "3"
 	Case GUICtrlRead($g_hR55) = $GUI_CHECKED
-		$g_aRouting[5] = "0:5"
+		$g_aRoutingFFmpeg[5] = "0:5"
+		$g_aRoutingBMX[5] = "4"
 	Case GUICtrlRead($g_hR65) = $GUI_CHECKED
-		$g_aRouting[5] = "0:6"
+		$g_aRoutingFFmpeg[5] = "0:6"
+		$g_aRoutingBMX[5] = "5"
 	Case GUICtrlRead($g_hR75) = $GUI_CHECKED
-		$g_aRouting[5] = "0:7"
+		$g_aRoutingFFmpeg[5] = "0:7"
+		$g_aRoutingBMX[5] = "6"
 	Case GUICtrlRead($g_hR85) = $GUI_CHECKED
-		$g_aRouting[5] = "0:8"
+		$g_aRoutingFFmpeg[5] = "0:8"
+		$g_aRoutingBMX[5] = "7"
 	Case GUICtrlRead($g_hRL5) = $GUI_CHECKED
-		$g_aRouting[5] = '"[L]"'
+		$g_aRoutingFFmpeg[5] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR5) = $GUI_CHECKED
-		$g_aRouting[5] = '"[R]"'
+		$g_aRoutingFFmpeg[5] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 6
 Select
 	Case GUICtrlRead($g_hRm6) = $GUI_CHECKED
-		$g_aRouting[6] = "1:0"
+		$g_aRoutingFFmpeg[6] = "1:0"
+		$g_aRoutingBMX[6] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR16) = $GUI_CHECKED
-		$g_aRouting[6] = "0:1"
+		$g_aRoutingFFmpeg[6] = "0:1"
+		$g_aRoutingBMX[6] = "0"
 	Case GUICtrlRead($g_hR26) = $GUI_CHECKED
-		$g_aRouting[6] = "0:2"
+		$g_aRoutingFFmpeg[6] = "0:2"
+		$g_aRoutingBMX[6] = "1"
 	Case GUICtrlRead($g_hR36) = $GUI_CHECKED
-		$g_aRouting[6] = "0:3"
+		$g_aRoutingFFmpeg[6] = "0:3"
+		$g_aRoutingBMX[6] = "2"
 	Case GUICtrlRead($g_hR46) = $GUI_CHECKED
-		$g_aRouting[6] = "0:4"
+		$g_aRoutingFFmpeg[6] = "0:4"
+		$g_aRoutingBMX[6] = "3"
 	Case GUICtrlRead($g_hR56) = $GUI_CHECKED
-		$g_aRouting[6] = "0:5"
+		$g_aRoutingFFmpeg[6] = "0:5"
+		$g_aRoutingBMX[6] = "4"
 	Case GUICtrlRead($g_hR66) = $GUI_CHECKED
-		$g_aRouting[6] = "0:6"
+		$g_aRoutingFFmpeg[6] = "0:6"
+		$g_aRoutingBMX[6] = "5"
 	Case GUICtrlRead($g_hR76) = $GUI_CHECKED
-		$g_aRouting[6] = "0:7"
+		$g_aRoutingFFmpeg[6] = "0:7"
+		$g_aRoutingBMX[6] = "6"
 	Case GUICtrlRead($g_hR86) = $GUI_CHECKED
-		$g_aRouting[6] = "0:8"
+		$g_aRoutingFFmpeg[6] = "0:8"
+		$g_aRoutingBMX[6] = "7"
 	Case GUICtrlRead($g_hRL6) = $GUI_CHECKED
-		$g_aRouting[6] = '"[L]"'
+		$g_aRoutingFFmpeg[6] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR6) = $GUI_CHECKED
-		$g_aRouting[6] = '"[R]"'
+		$g_aRoutingFFmpeg[6] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 7
 Select
 	Case GUICtrlRead($g_hRm7) = $GUI_CHECKED
-		$g_aRouting[7] = "1:0"
+		$g_aRoutingFFmpeg[7] = "1:0"
+		$g_aRoutingBMX[7] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR17) = $GUI_CHECKED
-		$g_aRouting[7] = "0:1"
+		$g_aRoutingFFmpeg[7] = "0:1"
+		$g_aRoutingBMX[7] = "0"
 	Case GUICtrlRead($g_hR27) = $GUI_CHECKED
-		$g_aRouting[7] = "0:2"
+		$g_aRoutingFFmpeg[7] = "0:2"
+		$g_aRoutingBMX[7] = "1"
 	Case GUICtrlRead($g_hR37) = $GUI_CHECKED
-		$g_aRouting[7] = "0:3"
+		$g_aRoutingFFmpeg[7] = "0:3"
+		$g_aRoutingBMX[7] = "2"
 	Case GUICtrlRead($g_hR47) = $GUI_CHECKED
-		$g_aRouting[7] = "0:4"
+		$g_aRoutingFFmpeg[7] = "0:4"
+		$g_aRoutingBMX[7] = "3"
 	Case GUICtrlRead($g_hR57) = $GUI_CHECKED
-		$g_aRouting[7] = "0:5"
+		$g_aRoutingFFmpeg[7] = "0:5"
+		$g_aRoutingBMX[7] = "4"
 	Case GUICtrlRead($g_hR67) = $GUI_CHECKED
-		$g_aRouting[7] = "0:6"
+		$g_aRoutingFFmpeg[7] = "0:6"
+		$g_aRoutingBMX[7] = "5"
 	Case GUICtrlRead($g_hR77) = $GUI_CHECKED
-		$g_aRouting[7] = "0:7"
+		$g_aRoutingFFmpeg[7] = "0:7"
+		$g_aRoutingBMX[7] = "6"
 	Case GUICtrlRead($g_hR87) = $GUI_CHECKED
-		$g_aRouting[7] = "0:8"
+		$g_aRoutingFFmpeg[7] = "0:8"
+		$g_aRoutingBMX[7] = "7"
 	Case GUICtrlRead($g_hRL7) = $GUI_CHECKED
-		$g_aRouting[7] = '"[L]"'
+		$g_aRoutingFFmpeg[7] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR7) = $GUI_CHECKED
-		$g_aRouting[7] = '"[R]"'
+		$g_aRoutingFFmpeg[7] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 ; track 8
 Select
 	Case GUICtrlRead($g_hRm8) = $GUI_CHECKED
-		$g_aRouting[8] = "1:0"
+		$g_aRoutingFFmpeg[8] = "1:0"
+		$g_aRoutingBMX[8] = "s1"
 		$g_bMuteRouted = True
 	Case GUICtrlRead($g_hR18) = $GUI_CHECKED
-		$g_aRouting[8] = "0:1"
+		$g_aRoutingFFmpeg[8] = "0:1"
+		$g_aRoutingBMX[8] = "0"
 	Case GUICtrlRead($g_hR28) = $GUI_CHECKED
-		$g_aRouting[8] = "0:2"
+		$g_aRoutingFFmpeg[8] = "0:2"
+		$g_aRoutingBMX[8] = "1"
 	Case GUICtrlRead($g_hR38) = $GUI_CHECKED
-		$g_aRouting[8] = "0:3"
+		$g_aRoutingFFmpeg[8] = "0:3"
+		$g_aRoutingBMX[8] = "2"
 	Case GUICtrlRead($g_hR48) = $GUI_CHECKED
-		$g_aRouting[8] = "0:4"
+		$g_aRoutingFFmpeg[8] = "0:4"
+		$g_aRoutingBMX[8] = "3"
 	Case GUICtrlRead($g_hR58) = $GUI_CHECKED
-		$g_aRouting[8] = "0:5"
+		$g_aRoutingFFmpeg[8] = "0:5"
+		$g_aRoutingBMX[8] = "4"
 	Case GUICtrlRead($g_hR68) = $GUI_CHECKED
-		$g_aRouting[8] = "0:6"
+		$g_aRoutingFFmpeg[8] = "0:6"
+		$g_aRoutingBMX[8] = "5"
 	Case GUICtrlRead($g_hR78) = $GUI_CHECKED
-		$g_aRouting[8] = "0:7"
+		$g_aRoutingFFmpeg[8] = "0:7"
+		$g_aRoutingBMX[8] = "6"
 	Case GUICtrlRead($g_hR88) = $GUI_CHECKED
-		$g_aRouting[8] = "0:8"
+		$g_aRoutingFFmpeg[8] = "0:8"
+		$g_aRoutingBMX[8] = "7"
 	Case GUICtrlRead($g_hRL8) = $GUI_CHECKED
-		$g_aRouting[8] = '"[L]"'
+		$g_aRoutingFFmpeg[8] = '"[L]"'
 		$g_bExternalWavRouted = True
 	Case GUICtrlRead($g_hRR8) = $GUI_CHECKED
-		$g_aRouting[8] = '"[R]"'
+		$g_aRoutingFFmpeg[8] = '"[R]"'
 		$g_bExternalWavRouted = True
 EndSelect
 #EndRegion - track setting
-;~ _ArrayDisplay($g_aRouting)
-For $i = 1 To UBound($g_aRouting) -1
-	ConsoleWrite($g_aRouting[$i] & @CRLF)
+;~ _ArrayDisplay($g_aRoutingFFmpeg)
+For $i = 1 To UBound($g_aRoutingFFmpeg) -1
+	ConsoleWrite($g_aRoutingFFmpeg[$i] & @CRLF)
 Next
 ConsoleWrite("$g_bMuteRouted: " & $g_bMuteRouted & @CRLF)
 ConsoleWrite("$g_bExternalWavRouted: " & $g_bExternalWavRouted & @CRLF)
@@ -546,9 +619,12 @@ SplashTextOn("Be patient", "MXF-Track-Swap will be prepared ...", 300, 50)
 If Not FileExists(@TempDir & "\ffmpeg.exe") Then
 	FileInstall('K:\ffmpeg\bin\ffmpeg.exe', @TempDir & "\ffmpeg.exe", $FC_OVERWRITE)
 EndIf
+If Not FileExists(@TempDir & "\bmxtranswrap.exe") Then
+	FileInstall('K:\bmxtranswrap\bmxtranswrap.exe', @TempDir & "\bmxtranswrap.exe", $FC_OVERWRITE)
+EndIf
 SplashOff()

-Local $sPathFFmpeg = @TempDir & "\"
+Local $sPathTempFolder = @TempDir & "\"
 Global $g_hTimerStart
 Global $g_sStdErrAll

@@ -595,65 +671,101 @@ EndFunc
 Func _ReWrap()
 	$g_hTimerStart = TimerInit()
 	GUIDelete($g_hGUI)
-	$g_hGUI = GUICreate("MXF-Track-Swap Muxing", 600, 160)
+	$g_hGUI = GUICreate("MXF-Track-Swap Muxing", 600, 240)
 	GUICtrlCreateLabel("MXF-File: " & _FileName($g_sMXFFile), 10, 10, 580, 30)
 	GUICtrlSetFont(-1, 14, 400, 0, "Courier New")
-	GUICtrlCreateLabel("Rewrapping:", 10, 50, 580, 30)
+	Global $g_hLabelInsert = GUICtrlCreateLabel("Insert Audio:", 10, 50, 580, 30)
 	GUICtrlSetFont(-1, 12, 400, 0, "Courier New")
 	Global $Progress1 = GUICtrlCreateProgress(10, 80, 580, 20)
-	Global $Edit = GUICtrlCreateLabel("", 10, 120, 260, 30)
+	GUICtrlCreateLabel("Rewrapping:", 10, 120, 580, 30)
+	GUICtrlSetFont(-1, 12, 400, 0, "Courier New")
+	Global $Progress2 = GUICtrlCreateProgress(10, 150, 580, 20)
+	Global $Edit = GUICtrlCreateLabel("", 10, 200, 260, 60)
 	GUICtrlSetFont(-1, 14, 400, 0, "Courier New")
-	Global $g_hLabelRunningTime = GUICtrlCreateLabel("", 440, 120, 150, 30, $SS_RIGHT)
+	Global $g_hLabelRunningTime = GUICtrlCreateLabel("", 440, 200, 150, 30, $SS_CENTER)
 	GUICtrlSetFont(-1, 14, 400, 0, "Courier New")
 	GUISetState(@SW_SHOW)

+	; do everything with bmxwrap at the end, as only this creates valid v1.3 mxf files
+	; bmxwrap can't insert external audio, so if that should be done, run ffmpeg first
+	Local $sFFmpegCommand, $sBMXCommand, $sSuffix, $sSuffixTemp
+	For $i = 1 To UBound($g_aRoutingFFmpeg) -1
+		$sSuffix &= '_' & $i & '-' & StringRegExpReplace(StringRegExpReplace($g_aRoutingFFmpeg[$i], "\d:", ""), '[\[\]"]', "")
+	Next
+	$sSuffixTemp = $sSuffix & '_ffmpegTemp.mxf"'
+	$sSuffix &= '.mxf"'
+
+	; this is the default bmxtranswrap command line
+	; set TC 10:00:00:00
+	$sBMXCommand = '-y 10:00:00:00'
+	; type RDD09
+	$sBMXCommand &= ' -t rdd9'
+	; Active Format Descriptor 4-bit code from table 1 in SMPTE ST 2016-1 - full frame 16:9
+	$sBMXCommand &= ' --afd 8'
+	; the ARD ZDF HDF profile for op1a/rdd9
+	$sBMXCommand &= ' --ard-zdf-hdf'
+	; print progress percentage to stdout
+	$sBMXCommand &= ' -p'
+	; set the wave essence descriptor channel assignment label which identifies the audio layout mode in operation
+	$sBMXCommand &= ' --audio-layout as11-mode-0'
+
+	If $g_bExternalWavRouted Then
+		; ffmpeg first
 		;~ Code zum Remuxen: Video erhalten, Audio: 1>5, 2>6, 3>3, 4>4, 5 mute, 6 mute, 7>L, 8>R
 		;~ ffmpeg -i Video.mxf  -f lavfi -i anullsrc=r=48000:cl=mono -i Stereo.wav -ar 48000 -filter_complex "[2:a]apad,channelsplit=channel_layout=stereo[L][R]" -map 0:0 -map 0:5 -map 0:6 -map 0:3 -map 0:4 -map 1:0 -map 1:0 -map "[L]" -map "[R]" -c:v copy -c:a pcm_s24le -shortest -y Video_swapped.mxf
-	Local $sCommand
 		; video file
-	$sCommand = '-i "' & $g_sMXFFile & '"'
+		$sFFmpegCommand = '-i "' & $g_sMXFFile & '"'
 		; muted source
 		If $g_bMuteRouted Then
-		$sCommand &= ' -f lavfi -i anullsrc=r=48000:cl=mono'
+			$sFFmpegCommand &= ' -f lavfi -i anullsrc=r=48000:cl=mono'
 		EndIf
 		; external wav file
-	If $g_bExternalWavRouted Then
-		$sCommand &= ' -i "' & $g_sWAVFile & '" -ar 48000 -filter_complex "['
+		$sFFmpegCommand &= ' -i "' & $g_sWAVFile & '" -ar 48000 -filter_complex "['
 		If Not $g_bMuteRouted Then
-			$sCommand &= '1'
+			$sFFmpegCommand &= '1'
 		Else
-			$sCommand &= '2'
-		EndIf
-		$sCommand &= ':a]apad,channelsplit=channel_layout=stereo[L][R]"'
+			$sFFmpegCommand &= '2'
 		EndIf
+		$sFFmpegCommand &= ':a]apad,channelsplit=channel_layout=stereo[L][R]"'
 		; video mapping
-	$sCommand &= ' -map 0:0'
+		$sFFmpegCommand &= ' -map 0:0'
 		; audio mapping
-	For $i = 1 To UBound($g_aRouting) -1
-		$sCommand &= ' -map ' & $g_aRouting[$i]
+		For $i = 1 To UBound($g_aRoutingFFmpeg) -1
+			$sFFmpegCommand &= ' -map ' & $g_aRoutingFFmpeg[$i]
 		Next
 		; copy video, set audio to 24 bit, use shortest file (always the mxf file) as length, overwrite existing file
-	$sCommand &= ' -c:v copy -c:a pcm_s24le -shortest -y'
+		$sFFmpegCommand &= ' -c:v copy -c:a pcm_s24le -shortest -y'
 		; set encoding date as ffmpeg otherwise wouldn't create a valid op1a v1.3 file
 		Local $sDate
 		$sDate = _NowCalc()
 		$sDate = StringReplace($sDate, "/", "-") & ".000" ; including ms
-	$sCommand &= ' -metadata creation_time="' & $sDate & '"'
+		$sFFmpegCommand &= ' -metadata creation_time="' & $sDate & '"'
 		; output file
-	Local $sSuffix
-	For $i = 1 To UBound($g_aRouting) -1
-		$sSuffix &= '_' & $i & '-' & StringRegExpReplace(StringRegExpReplace($g_aRouting[$i], "\d:", ""), '[\[\]"]', "")
+		$sFFmpegCommand &= ' "' & @TempDir & '\' & _StripFileExtension(_FileName($g_sMXFFile)) & $sSuffixTemp
+		ConsoleWrite("$sFFmpegcommand: " & $sFFmpegCommand & @CRLF)
+		_runFFmpeg('ffmpeg ' & $sFFmpegCommand, $sPathTempFolder)
+		; bmxtranswrap second
+		_runBMXwrap('bmxtranswrap ' & $sBMXCommand & ' -o "' & @TempDir & '\' & _StripFileExtension(_FileName($g_sMXFFile)) & $sSuffix & ' "' & @TempDir & '\' & _StripFileExtension(_FileName($g_sMXFFile)) & $sSuffixTemp, $sPathTempFolder)
+	Else
+		GUICtrlSetState($Progress1, $GUI_DISABLE) ; no external audio inserted
+		GUICtrlSetState($g_hLabelInsert, $GUI_DISABLE) ; no external audio inserted
+		; add audio mapping to bmx command
+		; '--track-map "4;5;0;1;2;3;s1;s1"'
+		; audio mapping
+		$sBMXCommand &= ' --track-map "'
+		For $i = 1 To UBound($g_aRoutingBMX) -1
+			$sBMXCommand &= $g_aRoutingBMX[$i] & ';'
 		Next
-	$sSuffix &= '.mxf"'
-	$sCommand &= ' "' & @TempDir & '\' & _StripFileExtension(_FileName($g_sMXFFile)) & $sSuffix
-	ConsoleWrite("$command: " & $sCommand & @CRLF)
-	_runFFmpeg('ffmpeg ' & $sCommand, $sPathFFmpeg, 1)
+		$sBMXCommand = StringTrimRight($sBMXCommand, 1) ; remove the last semicolon
+		$sBMXCommand &= '"'
+		_runBMXwrap('bmxtranswrap ' & $sBMXCommand & ' -o "' & @TempDir & '\' & _StripFileExtension(_FileName($g_sMXFFile)) & $sSuffix & ' "' & $g_sMXFFile & '"', $sPathTempFolder)
+	EndIf
 	GUICtrlSetData($Edit, "Ready")
 	WinSetOnTop($g_hGUI, "", $WINDOWS_ONTOP)

 EndFunc

-Func _runFFmpeg($command, $wd, $iProgress)
+Func _runFFmpeg($command, $wd)
 	Local $hPid = Run('"' & @ComSpec & '" /c ' & $command, $wd, @SW_HIDE, $STDOUT_CHILD + $STDERR_CHILD)
 	Local $sStdErr, $sTimer
 	Local $iTicksDuration = 0, $iTicksTime = 0, $iTimer
@@ -666,10 +778,31 @@ Func _runFFmpeg($command, $wd, $iProgress)
 			If Not $iTicksDuration Then $iTicksDuration = _GetDuration($sStdErr)
 			$iTicksTime = _GetTime($sStdErr)
 			If Not @error Then $sStdErr = ""
-			Switch $iProgress
-				Case 1
 			GUICtrlSetData($Progress1, $iTicksTime * 100 / $iTicksDuration)
-			EndSwitch
+		EndIf
+		$iTimer = TimerDiff($g_hTimerStart)
+		$sTimer = _Zeit($iTimer)
+		If GUICtrlRead($g_hLabelRunningTime) <> $sTimer Then
+			GUICtrlSetData($g_hLabelRunningTime, $sTimer)
+		EndIf
+	WEnd
+EndFunc
+
+Func _runBMXwrap($command, $wd)
+	ConsoleWrite("$sBMXcommand: " & $command & @CRLF)
+	Local $hPid = Run('"' & @ComSpec & '" /c ' & $command, $wd, @SW_HIDE, $STDOUT_CHILD + $STDERR_CHILD)
+	Local $sStdErr, $sTimer
+	Local $iPercent = 0, $iTimer
+	While 1
+		Sleep(500)
+		$sStdErr = StdoutRead($hPid)
+		If @error Then ExitLoop
+		$g_sStdErrAll &= $sStdErr
+		If StringLen($sStdErr) > 0 Then
+;~ 			ConsoleWrite("StdOut: " & $sStdErr & @CRLF)
+			$iPercent = _GetPercent($sStdErr)
+			If Not @error Then $sStdErr = ""
+			GUICtrlSetData($Progress2, $iPercent)
 		EndIf
 		$iTimer = TimerDiff($g_hTimerStart)
 		$sTimer = _Zeit($iTimer)
@@ -699,6 +832,17 @@ Func _GetTime($sStdErr)
    Return _TimeToTicks($aTime[0], $aTime[1], $aTime[2])
 EndFunc   ;==>_GetTime

+Func _GetPercent($sStdErr)
+    If Not StringInStr($sStdErr, "%") Then Return SetError(1, 0, 0)
+    Local $aRegExp = StringRegExp($sStdErr, "(?i)\d{1,2}\.\d%", 3)
+    If @error Or Not IsArray($aRegExp) Then Return SetError(2, 0, 0)
+    Local $sPercent = $aRegExp[0]
+	$sPercent = StringTrimRight($sPercent, 1) ; remove %
+	ConsoleWrite("Percent: " & $sPercent & @CRLF)
+    Return $sPercent
+EndFunc
+
+
 Func _FileName($sFullPath)
 	Local $iDelimiter = StringInStr($sFullPath, "\", 0, -1)
 	Return StringTrimLeft($sFullPath, $iDelimiter)

--- a/README.md
+++ b/README.md
@@ -4,9 +4,10 @@ Provide a mxf (tested only with xdcam hd 422 op1a including 8 audio tracks) and

 ## Prerequisites

-To build your swapper yourself you need a compiled ffmpeg that must be embedded into your swapper. Customize the following code line:
+To build your swapper yourself you need a compiled ffmpeg and bmxtranswrap that must be embedded into your swapper. Customize the following code lines:

 `FileInstall('K:\ffmpeg\bin\ffmpeg.exe', @TempDir & "\ffmpeg.exe", $FC_OVERWRITE)`
+`FileInstall('K:\bmxtranswrap\bmxtranswrap.exe', @TempDir & "\bmxtranswrap.exe", $FC_OVERWRITE)`

 ## Manual

@@ -45,5 +46,8 @@ The new mxf file will be created in `%temp%` folder. This folder will be opened

 The routing example in the image above would be named `Spurkennung_1-5_2-6_3-3_4-4_5-L_6-R_7-8_8-7.mxf`.

+## Insides
+Wrapping with ffmpeg can't create valid v1.3 op1a mxf in ard zdf profile. This is done with bmxtranswrap. Bmxtranswrap can swap audio tracks or mute them. But it can't insert external audio. So if external audio is provided the track swapping, muting and inserting is done with ffmpeg and the mxf is rewrapped with bmxtranswrap afterwards. Else the swapping and muting is done with bmxtranswrap alone.
+
 ## Known issues
 If you use only one track ot the external stereo wav file (e.g. "[R]") it breaks: "Filter channelsplit:FL has an unconnected outut".
--- a/images/MXF-Track-Swap_muxing.png
+++ b/images/MXF-Track-Swap_muxing.png
